EIFS / ETICS Additives for Adhesive, Base Coat and Finishing Mortars

Adhesive and base-coat additives for EPS, XPS and mineral-wool insulation systems.

LANDU: Your EIFS / ETICS Additives Manufacturer

An external thermal insulation composite system is only as good as its two thinnest layers: the 3–8 mm of adhesive that holds the insulation board to the wall and the 3–5 mm of base coat that carries the mesh and keeps rain out for 25 years. Both are polymer-modified dry mortars, and both pass or fail ETAG 004 / EAD 040083 on their additive package. This page sets out the Landercoll®, Accurate® and NOVASTAR® grades for each layer, the dosage ranges we start from, and the failures that European applicators report most often.

Three mortars, three briefs

LayerFunctionCritical requirements (EAD 040083-00-0404)Additive priorities
Adhesive mortarBonds EPS, XPS, mineral wool or wood-fibre boards to masonry or concreteBond to substrate ≥ 0.25 N/mm²; bond to EPS ≥ 0.08 N/mm² or board failure; tested dry, wet and after 2 h/7 d re-dryingWater retention on absorbent masonry, wet-out of EPS skin, open time for board adjustment, sag resistance under board weight
Base coat (reinforcing render)Embeds glass-fibre mesh, bridges cracks, resists impact and weatherWater absorption < 1 kg/m² after 24 h for base coat and complete render; hygrothermal cycling (heat–rain, heat–cold) without cracking or debonding; impact category I/II/III; freeze–thaw where requiredFlexibility (crack bridging), hydrophobicity, adhesion to EPS/MW, pumpability for machine application
Finishing render / decorative coat (mineral)Colour, texture, weather skinWater absorption, vapour permeability, freeze–thawWorkability, open time for floating, water repellency, efflorescence control

The same cellulose ether grade can serve all three layers; the polymer powder and hydrophobic components change layer by layer.

Grade selection

Landercoll® cellulose ether. Every grade below carries EIFS / ETICS on its technical data sheet: K100H (“EIFS and standard tile adhesives”), K150 (“EIFS/EITCS, tile adhesives, skim coat”), K200 and K200H (“tile adhesives, EIFS/EITCS, skim coat”), K40H (“premium tile adhesives and EIFS”), EM40HT (“EIFS — surface mortar and adhesive mortar”), EM100H (“cement-based tile adhesives and EIFS”) and EM200 (“tile adhesives, EIFS/EITCS”). K75 and EM80 are the cement render grades used for mineral finishing coats. Viscosities are Brookfield RV, 2 % solution, 20 °C.

MortarGrades (viscosity)Starting dosageWhy
Adhesive mortar, hand-appliedK150 (55,000–65,000) · K200 (65,000–80,000) / EM200 (65,000–80,000)0.30–0.40 %Water retention “very high” (K150) and sag resistance “excellent” (K200, EM200) for board weight on brick and AAC
Adhesive mortar, machine-appliedK100H (45,000–60,000) / EM100H (45,000–60,000)0.30–0.40 %Pumpable viscosity with high water retention; EM100H sag resistance “excellent”
Base coat, hand and machineK100H · K40H (20,000–24,000) / EM40HT (18,000–23,000)0.25–0.35 %Smooth mesh embedding, no sag at 4–5 mm; EM40HT is the TDS grade for EIFS surface mortar
Base coat for Southern Europe / summerEM40HT · EM100H (HEMC)0.30–0.40 %Heat resistance “excellent” on the HEMC TDS versus “standard” for HPMC
Mineral finishing renderK75 (35,000–40,000) / EM80 (35,000–45,000)0.15–0.25 %Cement render grades: float finish, texture stability

Accurate® redispersible polymer powder

MortarGrade familyGrades (TDS Tg / MFFT)Starting dosage
Adhesive mortar to EPS/XPSRigid or semi-flexible VAE5011N (Tg 10 ± 5 °C / 4 °C; TDS: adhesive and surface mortar for EIFS), 4025N (Tg 0 °C / 1 °C; TDS: adhesive mortar for EIFS)2–3 %
Adhesive mortar to mineral wool / wood fibreSemi-flexible4025N3–4 %
Base coat, standard (impact cat. III/II)Flexible5045N (Tg −10 ± 5 °C / 0 °C; TDS lists EIFS), 9055E acrylic–silane (Tg −15 °C / 0 °C)3–5 %
Base coat, high impact (cat. I) or renovation on old renderFlexible + strong hydrophobic5045N + 8035H (TDS: adhesive & base-coat mortars, mineral renders)5–8 % total
Base coat with declared low water absorptionHydrophobic8035H (strong hydrophobic effect), 8048H (very strong, instant-dissolving)3–5 %
Mineral finishing renderSemi-flexible or hydrophobic4025N, 8035H1–2 %

NOVASTAR® specialty additives

  • SHP75 / SHP80 silicone hydrophobic powder, 0.2–0.5 % (TDS range 0.1–0.5 %): the TDS names EIFS, stucco and façade render among its applications — it reduces capillary water transport and 24 h water absorption of base coats and finishing renders while keeping vapour permeability, with limited impact on mechanical properties.
  • Starch ether ST3511, 0.03–0.08 %: the TDS grade for “EIFS/ETICS insulation mortars, adhesive mortars and putty” — residue on ignition ≤ 1 %, neutral pH, improves wet adhesion and workability. ST3547 (universal grade for adhesive and thermal-insulation mortars) adds anti-sag under heavy boards.
  • PP fibre 3–6 mm, 0.05–0.15 %: plastic-shrinkage crack control in base coats applied in wind and sun.
  • Powder defoamer P805, 0.1–0.2 % (P806 alkali-resistant, P807 low-temperature): denser base coat, fewer pinholes in machine-sprayed layers.

Dosages are percentages of the total dry mix for laboratory starting points; the technical data sheets do not prescribe dosages. Verify against ETAG 004 / EAD 040083 test methods with your cement and sand.

Troubleshooting reported by ETICS applicators

SymptomLikely causeAdjustment
Boards debond with clean EPS surfaceMortar skinned before the board was pressed; low polymerK200H or EM40HT at 0.35–0.40 % for water retention; RDP ≥ 2.5 %; check EPS surface is dust-free and not UV-degraded
Boards slide after placementLow sag resistance0.05 % ST3547; K200 / EM200 instead of K100H (sag resistance “excellent” on the TDS); reduce water
Cracks along mesh overlapsBase coat too thin at overlap; rigid polymerMinimum 3 mm cover over mesh; flexible 5045N / 9055E ≥ 3 %; 0.1 % PP fibre
Map cracking of base coat in summerFast water loss on EPS in sunHEMC EM40HT or EM100H (heat resistance “excellent”); shade and mist-cure; fibre
Water uptake > 1 kg/m² at 24 hNo hydrophobic component; high w/cSHP 0.3 %; hydrophobic RDP 8035H; lower water with ST3511
Efflorescence on finishing renderSoluble salts carried by water movementSHP 0.3–0.5 %; hydrophobic RDP; low-alkali cement
Pump blockage, pulsing outputWater retention drops under pump pressure; airEM100H / EM40HT; defoamer P805; consistent water dosing
Freeze–thaw spalling of base coatLow polymer, high air, water uptakeRDP ≥ 4 % flexible; SHP; defoamer
Biological growth, dark streaksSurface stays wetHydrophobic additives; finishing render with lower water absorption

Related guides: EIFS adhesive formulation guide · Improving bonding strength in EIFS adhesives · What is an EIFS system · 5 Common EIFS Adhesive Problems Seen on Site.

Climate notes for European formulators

  • Nordic and Central Europe: freeze–thaw and driving rain dominate. Prioritise flexible RDP at the upper end of the range, hydrophobic powder in base coat and finish, and air content below 12 %.
  • Atlantic coast: long wet periods — hydrophobicity and vapour permeability together; avoid film-forming additives that seal the surface.
  • Mediterranean: open time and plastic shrinkage — HEMC grades (EM40HT, EM100H), fibre, and shading during application.
  • Renovation on existing render: adhesion to weak, chalky substrates — semi-flexible 4025N at 3–4 % in the adhesive and a bond-test (pull-off) before system approval.

Starting formulations (dry mix, laboratory basis)

ComponentAdhesive mortarBase coat
CEM I / CEM II 42.530–35 %25–30 %
Hydrated lime0–5 %3–5 %
Quartz sand 0.1–0.6 mm55–60 %55–60 %
Limestone filler / lightweight filler5–8 %5–10 %
Landercoll® cellulose etherK150 0.35 %EM40HT 0.30 %
Accurate® RDP4025N 2.5 %5045N 4 %
NOVASTAR® starch ether ST35110.05 %0.03 %
NOVASTAR® SHP75 / SHP80—0.3 %
PP fibre 6 mm—0.1 %
NOVASTAR® defoamer P805—0.15 %

Starting points only; the board type, substrate and target impact category determine the final polymer and hydrophobic dosage.

Supply for European ETICS manufacturers

LANDU manufactures Landercoll® cellulose ethers, Accurate® polymer powders and NOVASTAR® additives in three plants in Shandong (75,000 t/year) and has supplied dry-mortar producers in Europe since 2011. All grades are REACH-compliant and produced under ISO 9001; batch certificates follow every shipment. Stock is held with partners in several European countries, including Greece, Spain and Italy, for call-offs below a container; factory lead time is 7–15 working days. Packaging per TDS: 25 kg bags with PE inner liner, 500–600 kg pallets for cellulose ether and 600–1,300 kg pallets for RDP, neutral or OEM bags on request. Our application laboratory runs pull-off tests on EPS and mineral wool, water absorption and freeze–thaw screening on customer formulations.

Wall Putty / Skim Coat

Manufacturing & Production

See LANDU’s production facilities, manufacturing processes and industrial additive portfolio.

LANDU-The-Structure-of-an-EIFS-System

Quality Control & Assurance

Review LANDU’s approach to raw-material inspection, process control, batch tracking and finished-product testing.

midsection, hispanic, man, laying, tile, floor, new house, adults only, renovation, bathroom, aluminum, apartment, adult, blue-collar worker, building contractor, bangkok, building - activity, architecture, repairman, indoor, installing, horizontal, ceramic, working, home improvement, construction worker, occupation, house, person, one person, color image, industry, male, diy, cement, tiled floor, repairing, hand, new, concrete, construction site, craftsperson, professional occupation, work tool, material, glue, trowel, residential building, human body part, decoration

TDS, SDS & Batch COA

A Technical Data Sheet (TDS) describes the specifications and technical characteristics of a product grade. A Certificate of Analysis (COA) reports measured results for an identified production batch. Both documents support raw-material evaluation alongside application testing.

Contact LANDU about technical documents and batch-specific COA information for your selected material.

EIFS / ETICS Additives: Frequently Asked Questions

Answers on additive selection, testing, samples and supplier qualification.

How much RDP does an ETICS adhesive mortar need?

2–3 % for EPS and XPS boards, 3–4 % for mineral wool or wood-fibre boards, which have a more open surface. Accurate® 5011N and 4025N both list EIFS adhesive mortar on their technical data sheets. The target is board failure (cohesive failure in the insulation) in the ETAG 004 pull-off test rather than adhesive failure at the interface.

Which RDP for the base coat?

A flexible grade — Accurate® 5045N (Tg −10 ± 5 °C, MFFT 0 °C) or the acrylic–silane 9055E (Tg −15 °C) — at 3–5 %. It provides the crack bridging across board joints and the impact resistance the EAD requires. Add the strongly hydrophobic 8035H or 0.3 % SHP when a low water-absorption class is declared.

HPMC or HEMC for ETICS mortars?

Both are used. The HEMC data sheets (EM40HT, EM100H, EM200) rate heat resistance "excellent", so HEMC is preferred for machine application and for sites above 30–35 °C; HPMC (K100H, K150, K200, K200H) is the economical choice for hand-applied adhesive in temperate climates.

How do I bring water absorption under 1 kg/m² at 24 hours?

Three levers: 0.2–0.5 % NOVASTAR® SHP, a hydrophobic RDP grade (8035H or 8048H), and lower water demand through 0.03–0.05 % starch ether ST3511. Most base coats reach the threshold with SHP at 0.3 % plus 4 % flexible RDP.

Does cellulose ether affect adhesion to EPS?

Indirectly. Good water retention keeps the mortar surface wet long enough to wet out the EPS skin before the board is pressed; a mortar that skins in 10 minutes bonds poorly however much polymer it contains. Open time, controlled by the cellulose ether grade, is the first thing to check in a debonding case — K200H and EM40HT are the grades with the highest water retention on the TDS.

Can you supply test data to ETAG 004 / EAD 040083?

We supply technical data sheets, REACH documentation and application test reports from our laboratory (pull-off on EPS/MW, water absorption, freeze–thaw screening). The formal ETA is issued for the system holder's complete kit; we support the formulation work that leads to it.

Which additives are used in EIFS / ETICS adhesive and base coat mortar?

A cellulose ether for water retention and sag resistance (Landercoll® K150, K200 or EM200 at 0.30–0.40 % in the adhesive; K100H, K40H or EM40HT at 0.25–0.35 % in the base coat), a redispersible polymer powder for adhesion to the board and crack bridging in the base coat (Accurate™ 5011N or 4025N at 2–3 % in the adhesive; 5045N or 9055E at 3–5 % in the base coat), and, as the system requires, a starch ether for sag (ST3511), a hydrophobic powder or 8035H for declared water absorption, PP fibre and a defoamer.

Why is RDP used in polymer-modified EIFS?

The polymer film from the RDP is what bonds a cement mortar to EPS or mineral wool (cement paste alone has almost no adhesion to polystyrene) and what lets a 3–5 mm base coat follow the thermal movement of the board without cracking. Below about 2 % the adhesive fails at the board face; above 4–5 % cost rises faster than performance. The mesh carries the tensile load; the RDP keeps the base coat attached and flexible around it.

Are EIFS and ETICS the same thing?

Yes: insulation boards bonded and, where required, dowelled to the wall, a mesh-reinforced base coat and a finish. "EIFS" is the North American term, "ETICS" the European one. In Europe the system is assessed under EAD 040083 (formerly ETAG 004), which is where the bond, water absorption and impact requirements on this page come from. System overview: What is an EIFS system?.

What is the difference between polymer-based (PB) and polymer-modified (PM) EIFS?

North American terms. A PB system uses a thin, polymer-rich (acrylic-based) base coat of about 1.6 mm (1/16 in) over the insulation; a PM system uses a thicker cementitious base coat, typically 5–13 mm (3/16–1/2 in), modified with polymer and usually applied over a mechanically fixed board. The dry-mix adhesives and base coats on this page are the PM type and the European ETICS type: cement-based, polymer-modified with Accurate™ RDP and given their working properties by Landercoll® cellulose ether. Confirm the system class and its requirements in the system specification before selecting grades.

Can one mortar be used as both the adhesive and the base coat?

Yes, and "2-in-1" mortars are common: in practice the base-coat recipe (K100H or EM100H at 0.30–0.40 %, 3–4 % 4025N or 5045N) is also used for bonding. The cost is extra polymer in the adhesive layer, where 2–3 % would do. Qualify the two uses separately: bond to the board and to the substrate for the adhesive; water absorption, impact and crack bridging for the base coat.

Request Samples and a Grade Recommendation

Send us your adhesive and base-coat recipes, the board types you bond and your target impact category.

We return grade recommendations and dosages within two working days and ship samples free of charge.
